1962-1963 Ford Fairlane Aluminum Gauge Panel Adapter w/ Classic Instruments White Hot Gauges


Includes aluminum adapter panel & Classic Instruments White Hot gauges

Gauges included in this package:

  • 3 3/8″ electric speedometer (140 MPH or 200 KPH)
  • 3 3/8″ 8,000 RPM electric tachometer
  • 3 3/8″ Quad gauge (oil pressure, water temperature, fuel level, & voltmeter)
  • Includes oil pressure, water temperature, & speedometer senders

A fuel sender will be included when 240-33 ohms is selected for the fuel gauge.

Turn signal upgrades will be mounted into the speedometer as green turn signals at 3 o’clock and 9 o’clock and a blue high beam at 12 o’clock.

Please put your requirements in the notes, if you require a different configuration.
Mounts into stock bezel. Bezel NOT included.


LEDTH LED Upgraded (standard upgrade will consist of 2 green & 1 blue)
LEDHTH Halo LED upgrade (standard upgrade will consist of 2 green & 1 blue)
Lens options: Curved Glass vs. Flat Glass
White Hot information screen (optional)

Classic Instruments is excited to share this all-new hybrid gauge that successfully melds the nostalgic taste of analog gauges with the modern convenience of a digital readout. The new screen offers the end-user the ability to display an odometer, which “rolls” just like a traditional mechanical odometer, a digital speed readout in either miles per hour or kilometers per hour, as well as a trip meter. Additionally, the user can select whether the display uses English or Metric units and each new speedometer is equipped with a step-by-step calibration mode and enhanced diagnostic features.

Additional information

Weight 7.5 lbs
Dimensions 17 × 11.5 × 5.5 in
Adapter Panel Finsih

Brushed, Brushed & Black Anodized, Polished

Speedometer Options

Miles Per Hour (140), Kilometers Per Hour (200)


Ford, GM (non LS), LS, Mopar

Fuel Gauge Options

75-10 ohms (works w/ stock sender), 0-90 ohms (late GM), 0-30 ohms (early GM, 240-33 ohms
