1967-1972 Chevy Truck Aluminum Gauge Panel w/ Auto Meter Ultra-Lite Gauges

Name: 1967-1972 Chevy Truck Aluminum Gauge Panel w/ Auto Meter Ultra-Lite Gauges
SKU: 16003-UL
Availability: InStock

$939.95 – $1,225.00

Includes aluminum dash insert, Auto Meter Ultra-Lite gauges, & turn signal/high beam indicators.

Gauges include:

5” speedometer (choose from drop down menu)
5″ 10,000 RPM tachometer
2 5/8” 100 PSI oil pressure
2 5/8” 100-250 F water temperature
2 5/8” 8-18 VDC voltmeter
2 5/8” fuel level (choose from drop down list)
Sending units are included for the oil pressure & water temperature gauges.

The stock dash must be cut to accept this panel.
Installation Instructions

Gauge Panel Finish

Speedometer Options

Clear

Additional information

Weight	12 lbs
Dimensions	23 × 12.5 × 6 in
Gauge Panel Finish	Brushed Finish, Polished Finish, Brushed Black Finish
Fuel Options	0-90 ohms (works w/ stock sender), 240-33 ohms (works with ATM3262), 75-10 (Pre 87 Ford)
Speedometer Options	160 MPH Mechanical, 160 MPH Electric Speedometer, 260 KPH Electric Speedometer, 140 MPH GPS (built in) Speedometer, 225 KPH GPS (built in) Speedometer
